188116
1/5
Preview
PREVIEW
PLID
Manufacturer Type Description
MANUTYPEDESC
Short Description
DESCSHORT
Long Description
DESCLONG
International product number
INTNO
Netto weight
NETTO_WEIGHT [kg]
ECLASS-13.0
ECLASS_13_0
ETIM-9.0
ETIM_9_0
Resistance [EF002431]
EF002431 [O]
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
187046
M30C-FR1M-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 1000 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 1000 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821129
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
1000000
187039
M30C-FR2K2-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 2.2 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 2.2 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821051
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
2200
188114
M30I-FR10K
Potentiometer, flat front, M30, 30.5 mm, R 10 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 10 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857920
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
10000
187043
M30C-FR47K-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 47 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 47 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821099
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
47000
187040
M30C-FR4K7-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 4.7 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 4.7 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821068
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
4700
188110
M30I-FR47K
Potentiometer, flat front, M30, 30.5 mm, R 47 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 47 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857883
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
47000
188112
M30I-FR470K
Potentiometer, flat front, M30, 30.5 mm, R 470 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 470 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857906
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
470000
187031
M30C-FR47K
Potentiometer, flat front, M30, 30.5 mm, R 47 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 47 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081820979
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
47000
187041
M30C-FR10K-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 10 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 10 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821075
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
10000
188121
M30I-FR22K-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 22 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 47 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857999
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
22000
188116
M30I-FR1M
Potentiometer, flat front, M30, 30.5 mm, R 1000 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 1000 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857944
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
1000000
187042
M30C-FR22K-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 22 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 47 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821082
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
22000
232236
M22S-R470K
Potentiometer, Classical, M22, 22.5 mm, R 470 kΩ, P 0.5 W, Bezel: black
Potentiometer, RMQ design: Classical, Part group reference (e.g. DIL): M22, Mounting hole diameter: 22.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 470 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Bezel: black, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015082322366
0.03400
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
470000
188111
M30I-FR100K
Potentiometer, flat front, M30, 30.5 mm, R 100 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 100 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857890
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
100000
187045
M30C-FR470K-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 470 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 470 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821112
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
470000
188118
M30I-FR2K2-BLANK
Potentiometer, flat front, M30, 30.5 mm, Without scale/inscription, R 2.2 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Without scale/inscription, Impedance: R= 2.2 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857968
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
2200
188127
M30I-FR-SWD
Potentiometer, flat front, M30, 30.5 mm, Front ring stainless steel
Potentiometer, Subrange: SmartWire-DT RMQ connections, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: Front element SmartWire-DT potentiometer, Only in conjunction with M22-SWD-R function element, Function: For connecting to SmartWire-DT, Degree of Protection: IP65, Front ring stainless steel, Connection to SmartWire-DT: yes, Standards: IEC/EN 60947
4015081858057
0.05000
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
0
188113
M30I-FR2K2
Potentiometer, flat front, M30, 30.5 mm, R 2.2 kΩ, P 0.5 W, Front ring stainless steel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 2.2 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Front ring stainless steel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081857913
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
2200
187037
M30C-FR1M
Potentiometer, flat front, M30, 30.5 mm, R 1000 kΩ, P 0.5 W, Metal bezel
Potentiometer, RMQ design: flat front, Part group reference (e.g. DIL): M30, Mounting hole diameter: 30.5 mm, Single unit, Description: 3 individual screw terminals, Accuracy of resistance value: ± 10% (linear), Impedance: R= 1000 kΩ, Rated power: P= 0.5 W, Degree of Protection: IP66, Metal bezel, Connection to SmartWire-DT: no, Standards: IEC/EN 60947, VDE 0660
4015081821037
0.05500
Potentiometer for command devices [AKF045019]
Potentiometer for command devices [EC001027]
1000000
